RIV606 is an automatic feeder for blind rivets to be combined with a tool for blind rivets.
It can be used with rivets from d.6,0 to d.6,4mm (head must not exceed 10mm and the length of the nail must be less than 50mm).
Not for structural rivets.
For blind rivets d.2,4, 2,9 e 3,2mm the tool is prepared on client’s request.
The automatic blind rivet feeder is a pneumatic and electric tools, which allows to insert the blind rivet directly inside the head of the tool, the riveting implementation time has halved.
This solution avoids the contact between the hand of operator and the riveting tool, giving a 100% safety.
RIV606 can be used only with riveting tool fitted with vacuum exhaust and mandrel storage system, such as RIV502 – RIV503 – RIV504 – RIV505 (tool to be ordered separately).
